INTRODUCING THE ALII TOOL

ALII – Artificial Lift Intake Isolation Tool

The ALII Tool is a tubing isolation valve that provides positive well control before breaking wellhead containment.

Significant​ ​expenses​ ​associated​ ​with​ ​the​ ​recovery ​and​ ​disposal​ ​of​ ​kill​ ​fluids will now be non-existent.

The ALII Tool ​is​ ​a​ ​tubing​ ​isolation​ ​valve​ ​that​ ​provides​ ​positive​ ​well​ ​control before​ ​breaking​ ​wellhead​ ​containment.​ ​By​ ​design,​ ​the​ ​patented​ ALII​ ​is​ ​the only​ ​tubing​ ​isolation​ ​valve​ ​that​ ​utilizes​ ​the​ ​existing​ ​rod​ ​pump​ ​and​ ​rod​ string​ ​to function​ ​the​ ​valve​ ​open​ ​and​ ​close.​ ​

ALII ​allows​ ​you​ ​to change​ ​a​ polish rod​ ​or​ ​surface​ a ​rod​ ​pump​ ​under​ ​any​ ​condition,​ ​regardless​ ​of​ ​harmful​ ​gases, bottom​ ​hole​ ​pressure​ ​or​ ​temperature.​ ​The​ ​system​ ​eliminates​ ​the​ ​requirement​ ​for water​ ​or​ ​other​ ​more​ ​undesirable​ ​viscous​ ​fluids​ ​to​ ​maintain​ ​well​ ​control.​ ​A​ ​small amount​ ​of​ ​degreaser​ ​or​ ​de-waxer​ ​is​ ​all​ ​that is​ ​needed​ ​to​ ​clean​ ​the​ ​sucker​ ​rod​ ​string before​ ​surfacing​ ​it.​ Cost reductions will be drastic and immediate. ​

Environment

Extremely environmentally friendly and committed to reducing the environmental footprint by decreasing the use of local water supplies significantly and eliminating the disposal of recovered kill fluids.

Safety

New patented technology isolates the production tubing string in an oil well, provides positive well control and eliminates the need to “kill the well” before breaking containment at the wellhead.

Product Service

Our primary product is the patented Artificial Lift Intake Isolation Tool. The ALII tool is a unique and innovative solution for increased cost efficiency.

What makes ALII different:

By design, the Patented ALII Tool is the only tubing isolation valve that utilizes the existing rod pump and rod string to function the valve.

ALII can be installed on any artificial lift well that utilizes sucker‐rod pumping system.
The ALII Tool offers a unique advantage in the market by being the only tubing isolation valve that does not require the pump and rod string to be removed from the well post installation.
ALII does not require additional equipment to be added to the wellbore design to operate the valve (i.e. external control lines, clamps and bands, etc.).

Product specifications

  • Easy to install, end user friendly, minimal training
  • Multiple sizes: 2 3/8” to 5 1⁄2” (73mm to 139.7mm)
  • Tested and able to resist external pressure up to 10,152psi (70,000 kpa)
  • Suitable for high temperature thermal wells Max 650 degrees F (343 degrees C)

Product Composition:

  • Standard Tool is manufactured with L‐80 exterior components and L‐80 Boronize internal components.
  • The ALII can be manufactured in 13 Chrome – P 110 Inconel, Stainless Steel, etc.
  • It can be dressed with high temperature seals.
  • Shear pins for snubbing‐in on high pressure wells.

Water & Cost Savings

Water Useage

Traditional Method

Total Treatment cost of $609,164

ALII Method

Total Treatment cost SAVINGS of $487,333

Other ALII Products

ALII Tubing Insert Valve (TIV)

ALII Pump Through Single Barrier

ALII Pump Through Double Barrier
